Hikvision DS-3E0106HP-E network switch Unmanaged Fast Ethernet (10/100) Blue Power over Ethernet (PoE)

Hikvision 4-ports 100Mbps long-range unmanaged PoE+ switch

DS-3E0106HP-E switches are layer 2 100 Mbps long-range PoE switches, providing 1 × 10/100 Mbps Hi-PoE port, 3 × 10/100 Mbps PoE ports, and 2 × 10/100 Mbps RJ45 ports. The switches provide advanced Hi-PoE/PoE technology and support extend mode with long-range access up to 250 m. The prior and stable transmission of the important surveillance area videos can also be guaranteed when connected to the high priority ports. Meanwhile, the 2 × 10/100 Mbps RJ45 uplink ports guarantee applications of multiple network solutions.

• Up to 250m transmission achievable at reduced mbps rate
• IEEE 802.3at/af/bt standard for Hi-PoE port (Max. 60 W port power
• IEEE 802.3at/af standard for PoE ports
• IEEE 802.3, IEEE 802.3u, and IEEE 802.3x standard
• 1 × 10/100 Mbps Hi-PoE port, 3 × 10/100 Mbps PoE ports, and 2 × 10/100 Mbps RJ45 ports
• Provides up to 30 watts per PoE port
• PoE power budget 60W
• 6 kV surge protection for PoE ports
• Plug-and-play installation
• 1.2 Gbps switching fabric
• 768 Kbits RAM Data Buffer
• 2K MAC address entries
• Sturdy metal enclosure
• Dimensions: 145 x 25.6 x 68.45mm
